Home > Diesel Engine > 4-stroke Diesel Engine with 9.0HP Single Cylinder and Optional Electric Starter

4-stroke Diesel Engine with 9.0HP Single Cylinder and Optional Electric Starter

Product Name: 4-stroke Diesel Engine with 9.0HP Single Cylinder and Optional Electric Starter
Model NO.: WE186F

Product Details: 4-stroke Diesel Engine with 9.0HP Single Cylinder and Optional Electric Starter

Features and Benefits:

● direct injection combustion system
● efficient air cleaner system
● compact in structure and small in size
● multi-choice PTO shafts are available
● recoil manual starter and optional electric starting

About:
9.0HP,Easy and fast starting,Diesel,Single Cylinder,4-Stroke,Recoil Start & electric starting.

Description:

Model	WE186F
Engine Type	Single Cylinder,Air-cooled,4-stroke vertical
BorexStroke(mm)	86x70
Displacement	406cc
Compression Ratio	20:1
Max Power Output	9PS(6.6kW)/3600rpm
Recommded Power Using	8.6PS(6.3kW)/3600rpm
Start Model	Recoil / Electric Start
Rotating Direction	Clockwise
Fuel Tank Capaclty (L/gal)	5.5 / 1.45
Fuel Consumption	270 g/kWh
Fuel	0#(summer),-10# or -20# (winner) diesel
Lube	Oil SAE 10W30
Packing Dimensions (mm/in.)	500x470x530 / 19.7x18.5x20.9
Net Weight (kg/lb)	53 / 116.9
