9.0HP Single Cylinder Gasoline Engine with Lower Fuel Consumption and Electronic Ignition

Product Name: 9.0HP Single Cylinder Gasoline Engine with Lower Fuel Consumption and Electronic Ignition
Model NO.: WE177F/WE177FE

Product Details: 9.0HP Single Cylinder Gasoline Engine with Lower Fuel Consumption and Electronic Ignition

Features and Benefits:

● Auto decompressing makes starting easy
● OHV leads to the lower fuel consumption
● Oil alert automatically shut off the engine
● Electronic ignition
● Recoil starter makes the safe starting
● Auto decompressing makes easy starting

About:
9.0HP,Easy-pull, quick starting,Gasoline,Single Cylinder,4-Stroke,OHV,Recoil Start & electric starting.

Description:

Model	WE177F/WE177FE
Engine Type	Single Cylinder,Air-cooled,4-stroke OHV
BorexStroke(mm)	77x58
Displacement	270cc
Compression Ratio	8.5:1
Max Power Output	9PS(6.6kW)/3600rpm
Recommded Power Using	8PS(5.7kW)/3600rpm
Ignltion System	TCI
Start Model	Recoil / Electric Start
Fuel	93# or 97#
Fuel Tank Capaclty (L/gal)	6 / 1.6
Fuel Consumption	275 g/PS-hr(374 g/kWh)
Oil Capacity (L/gal)	1.1 / 0.29
Packing Dimensions (mm/in.)	500x420x470 / 19.7x16.5x18.5
Net Weight (kg/lb)	26 / 57.3
