1.5-inch Water Pump Set with 42m Maximum Total Bead and 40/25mm Inlet Size

Product Name: 1.5-inch Water Pump Set with 42m Maximum Total Bead and 40/25mm Inlet Size
Model NO.: WP15H

Product Details: 1.5-inch Water Pump Set with 42m Maximum Total Bead and 40/25mm Inlet Size

Features and Benefits:

● 1.5" High Pressure Water Pump powered by 4-stroke OHV gasoline engine.
● High pressure water discharge can reach more than 42m.
● Self suction and high-pressure structure.
● Pressure casting aluminum pump body.
● High quality mechanical seal equipment.

About:
1.5 inch,10(m3/h),High Pressure Water Pump
5.5PS,Gasoline Engine,Single Cylinder,4-Stroke,OHV,Recoil Start.

Description:

Model		WP15H
Name		High Pressure Water Pump
Pump	Inlet mm(inch)	40(1.5" )/25(1" )
	Outlet mm(inch)	40(1.5" )
	Max. Capacity (m3/h)	10
	Max. total head (m)	42
	Max. suction head (m)	8
Engine	Model	WE168F-1
	Type	Air-Cooled ,4-stroke,OHV,Gasoline Engine
	Displacement (cc)	196
	Max.output (ps/rpm)	6.5/3600
	lgnition system	Non-contact transistorized ignition (T.C.I)
	Starting system	Recoil and hand-operateg
	Muffler	Half-dry,double-strainer
	Tank capacity (l)	3.6
	Oil capacity (l)	0.6
Package	Dimension (LWH)mm	510385415
Package	G.W(kg)	30

Product Images: 1.5-inch Water Pump Set with 42m Maximum Total Bead and 40/25mm Inlet Size
